Plastic Ceiling Panel Production Line

Plastic Ceiling Panel Production Line is used to produce PVC wall panel with width normally from 250mm to 300mm with different section shape and height,the surface of PVC ceiling panel can be trested by double by hot stamping printing,or by lamination,which can make marble,wooden design on surface of product.

Send Inquiry

Product Description

WPC PVC Ceiling Panel Extruder Machine Line

WPC PVC Ceiling panel Extruder machine line Featrues

The Plastic Ceiling Panel Production Line is tailored for door manufacturing, featuring a conical double-screw extruder. The raw materials used in the WPC door making machine include wood powder, PVC powder, CaCo3 powder, and various additives. Additionally, the PVC WPC door making machine offers versatility, capable of producing various profiles such as windows, doors, door frames, pallets, outdoor wall cladding, park facilities, flooring, and more. This flexibility is achieved by simply changing the mold and other machine components as needed.

WPC PVC Ceiling Panel Extruder Machine Line

WPC PVC Ceiling panel Extruder machine line parameter

model	YF600	YF800	YF1000	YF1250
Max. Width of product	600	800	1000	1250
Extruder model	SJZ-80/156	SJZ-80/156	SJZ-92/188	SJZ-92/188
Max extruder capacity(kg/h)	280	280	450	450
Extruder power	55	55	110	132
Cooling water consumption(m3/h)	12	13	15	18
Compressed air consumption(m3/h)	0.5	0.6	0.8	1
